SAE AS22759 (M22759, MIL-W-22759) Mil-Spec Wire & Cable

信息来源：三博电子作者：三博电子时间：2018/6/11

SAE AS22759 (M22759, MIL-W-22759) Mil-Spec Wire & Cable

SAE AS22759 wire is a fluoropolymer–insulated single-conductor wire that is ideal for a wide variety of military aerospace applications. Since AS22759 wire is built to meet military specifications, it is also the premier choice for many commercial applications.SAE AS22759 wire boasts high performance and reliability in severe wind and moisture prone (SWAMP) zones such as engine nacelles as well as areas that require overload stability, low smoke emission and fire resistance, such as aircraft cabins.
Some of the distinctive characteristics offered by AS22759 wire are:

Excellent thermal stability
High reliability
High break strength and flex life
High abrasion resistance
AS22759 wire is available in sizes from 30 to 0000 AWG.
Note: This specification was formerly listed under MIL-W-22759.

SAE AS22759 Product Specifications

This wire is in full compliance with the SAE AS22759 specification provided by the Society of Automotive Engineers (SAE).

SPHSCA stands for silver-plated high strength copper alloy, and NPHSCA stands for nickel-plated high strength copper alloy.

PIN AWG Conductor Plating Voltage Temp Insulation M27500 Designation

M22759/1 22-04 Silver 600 200?C PTFE and PTFE Coated Glass EA

M22759/2 22-04 Nickel 600 260?C PTFE and PTFE Coated Glass E

M22759/3 22-02 Nickel 600 260?C TFE Glass TFE RA

M22759/4 22-02 Silver 600 200?C TFE-Glass-FEP RB

M22759/5 24-4 Silver 600 200?C Abrasion Resistant Mineral Filled TFE VA

M22759/6 24-4 Nickel 600 260?C Abrasion Resistant Mineral Filled TFE WA

M22759/7 24-4 Silver 600 200?C Abrasion Resistant Mineral Filled TFE SA

M22759/8 24-4 Nickel 600 260?C Abrasion Resistant Mineral Filled TFE TA

M22759/9 28-8 Silver 1000 200?C Extruded TFE LE

M22759/10 28-8 Nickel 1000 260?C Extruded TFE LH

M22759/11 28-8 Silver 600 200?C Extruded TFE RC

M22759/12 28-8 Nickel 600 260?C Extruded TFE RE

M22759/13 24-01 Tin 600 135?C FEP-PVF2 CA

M22759/14 26-12 Tin 600 135?C FEP-PVF2 CB

M22759/15 26-20 SPHSCA 600 135?C FEP-PVF2 CC

M22759/16 24-02 Tin 600 150?C Extruded ETFE TE

M22759/17 26-20 SPHSCA 600 150?C Extruded ETFE TF

M22759/18 26-10 Tin 600 150?C Extruded ETFE TG

M22759/19 26-20 SPHSCA 600 150?C Extruded ETFE TH

M22759/20 28-20 SPHSCA 1000 200?C Extruded TFE TK

M22759/21 28-20 NPHSCA 1000 260?C Extruded TFE TL

M22759/22 28-20 SPHSCA 600 200?C Extruded TFE TM

M22759/23 28-20 NPHSCA 600 260?C Extruded TFE TN

M22759/28 28-8 Silver 600 200?C Extruded TFE with Polyimide Coating JB

M22759/29 28-8 Nickel 600 260?C Extruded TFE with Polyimide Coating JC

M22759/30 28-20 SPHSCA 600 200?C Extruded TFE with Polyimide Coating JD

M22759/31 28-20 NPHSCA 600 260?C Extruded TFE with Polyimide Coating JE

M22759/32 30-12 Tin 600 150?C Crosslinked Modified ETFE SB

M22759/33 30-20 SPHSCA 600 200?C Crosslinked Modified ETFE SC

M22759/34 24-02 Tin 600 150?C Crosslinked Modified ETFE SD

M22759/35 26-20 SPHSCA 600 200?C Crosslinked Modified ETFE SE

M22759/41 26-02 Nickel 600 200?C Crosslinked Modified ETFE SM

M22759/42 26-20 NPHSCA 600 200?C Crosslinked Modified ETFE SN

M22759/43 26-02 Silver 600 200?C Crosslinked Modified ETFE SP

M22759/44 28-12 Silver 600 200?C Crosslinked Modified ETFE SR

M22759/45 28-12 Nickel 600 200?C Crosslinked Modified ETFE SS

M22759/46 28-20 NPHSCA 600 200?C Crosslinked Modified ETFE ST

M22759/80 26-10 Tin 600 150?C PTFE/Polyimide WB

M22759/81 26-20 Silver 600 200?C PTFE/Polyimide WC

M22759/82 26-20 NPHSCA 600 260?C PTFE/Polyimide WE

M22759/83 8-04 Silver 600 200?C PTFE/Polyimide WF

M22759/84 8-04 Nickel 600 260?C PTFE/Polyimide WG

M22759/85 8-04 Tin 600 150?C PTFE/Polyimide WH

M22759/86 26-04 Silver 600 200?C PTFE/Polyimide WJ

M22759/87 26-04 Nickel 600 260?C PTFE/Polyimide WK

M22759/88 26-04 Tin 600 150?C PTFE/Polyimide WL

M22759/89 26-20 SPHSCA 600 200?C PTFE/Polyimide WM

M22759/90 26-20 NPHSCA 600 260?C PTFE/Polyimide WN

M22759/91 26-10 Silver 600 200?C PTFE/Polyimide WP

M22759/92 26-10 Nickel 600 260?C PTFE/Polyimide WR

M22759/180 26-10 Tin 600 150?C PTFE/Polyimide with Seamles PTFE tape DB

M22759/181 26-20 Silver 600 200?C PTFE/Polyimide with Seamles PTFE tape DC

M22759/182 26-20 NPHSCA 600 260?C PTFE/Polyimide with Seamles PTFE tape DE

M22759/183 8-04 Silver 600 200?C PTFE/Polyimide with Seamles PTFE tape DF

M22759/184 8-04 Nickel 600 260?C PTFE/Polyimide with Seamles PTFE tape DG

M22759/185 8-04 Tin 600 150?C PTFE/Polyimide with Seamles PTFE tape DH

M22759/186 26-04 Silver 600 200?C PTFE/Polyimide with Seamles PTFE tape DJ

M22759/187 26-04 Nickel 600 260?C PTFE/Polyimide with Seamles PTFE tape DK

M22759/188 26-04 Tin 600 150?C PTFE/Polyimide with Seamles PTFE tape DL

M22759/189 26-20 SPHSCA 600 200?C PTFE/Polyimide with Seamles PTFE tape DM

M22759/190 26-20 NPHSCA 600 260?C PTFE/Polyimide with Seamles PTFE tape DN

M22759/191 26-10 Silver 600 200?C PTFE/Polyimide with Seamles PTFE tape DP

M22759/192 26-10 Nickel 600 260?C PTFE/Polyimide with Seamles PTFE tape DR

RELATED PRODUCTS

M27500

(NEMA WC27500)

MIL-DTL-81381

(MIL-W-81381)

MIL-DTL-25038

(M25038)

SAE AS81044

(M81044)

SAE AS22759/32 (M22759/32)

Mil-Spec Wire & Cable
SAE AS22759

SAE AS22759/32 wire is constructed using a tin-plated copper conductor with crosslinked ETFE insulation (150°C) for extra flexibility and ease of soldering. This combination is also well-suited for commercial or aerospace environments that require protection against vibration, smoke, flame, etc.

Conductor: Tin-plated copper
Insulation: Crosslinked, modified ETFE
Voltage Rating: 600V
Temperature Rating: 150°C

SAE AS22759/32 Part Numbers

Part Number AWG Stranding Conductor
Diameter
(in) Insulation
Diameter (in) Weight
(LBS/MFT) Max. Resistance @
20°C OHMS/MFT
Min. Max.
M22759/32-12-* 12 37/28 .084 .089 .103 ± .003 19.7 2.02
M22759/32-14-* 14 19/27 .065 .069 .085 ± .002 13.0 3.06
M22759/32-16-* 16 19/29 .052 .055 .068 ± .002 8.3 4.81
M22759/32-18-* 18 19/30 .046 .049 .060 ± .002 6.5 6.23
M22759/32-20-* 20 19/32 .037 .039 .050 ± .002 4.3 9.88
M22759/32-22-* 22 19/34 .029 .031 .043 ± .002 2.8 16.2
M22759/32-24-* 24 19/36 .023 .025 .037 ± .002 2.0 26.2
M22759/32-26-* 26 19/38 .018 .020 .032 ± .002 1.4 41.3
M22759/32-28-* 28 7/36 .014 .016 .027 ± .002 .91 68.6
M22759/32-30-* 30 7/38 .011 .013 .024 ± .002 .66 108.4
*Add color coding according to MIL-STD-681.

0=black 1=brown 2=red 3=orange 4=yellow 5=green 6=blue 7=violet 8=gray 9=white
SAE AS22759/33 (M22759/33)

Mil-Spec Wire & Cable
SAE AS22759

Featuring crosslinked ETFE insulation over a silver-plated, high-strength copper alloy conductor, SAE AS22759/33 wire has a temperature rating of 200°C. Ideal applications include commercial and aerospace applications such as engine controls or aircraft cabins.

Conductor: Silver-plated, high-strength copper alloy
Insulation: Crosslinked, modified ETFE
Voltage Rating: 600V
Temperature Rating: 200°C

SAE AS22759/33 Part Numbers

Part Number AWG Stranding Conductor
Diameter
(in) Insulation
Diameter (in) Weight
(LBS/MFT) Max. Resistance @
20°C OHMS/MFT
Min. Max.
M22759/33-20-* 20 19/32 .037 .039 .050 ± .002 4.4 10.7
M22759/33-22-* 22 19/34 .029 .031 .043 ± .002 2.9 17.5
M22759/33-24-* 24 19/36 .023 .025 .037 ± .002 2.0 28.4
M22759/33-26-* 26 19/38 .018 .020 .032 ± .002 1.4 44.8
M22759/33-28-* 28 7/36 .014 .016 .027 ± .002 .91 74.4
M22759/33-30-* 30 7/38 .011 .012 .024 ± .002 .66 117.4
*Add color coding according to MIL-STD-681.

0=black 1=brown 2=red 3=orange 4=yellow 5=green 6=blue 7=violet 8=gray 9=white
